Innobrace is proud to introduce the revolutionary Epsilon non-ligating bracket (NLB) ~ Flexibrace series onto the market - a new orthodontic device, developed in collaboration with Singapore Institute of Manufacturing Technology (SIMTECH) - a research institute of the Agency for Science, Technology and Research (A*STAR).
Flexibrace is a one piece Roth-Type bracket utilising a highly flexible arch wall engagement system, thereby securing the arch wire without the need to engage/disengage metal clips or affix elastomeric devices, making this innovation truly one of its kind and the 1st non-ligating bracket system in the world.
This unique Flexibrace design has received its U.S Patent in year 2018. Flexibrace has been shown to cut chair time by up to 50% and total treatment duration by more than 33%. Flexibrace allows dental professionals to progress faster to wire size changes, resulting in a faster completion time, yet ensuring patient comfort through gentle continuous forces.
One key feature of Flexibrace is its flexible archwire slot, which no other bracket systems in the industry has. Excessive forces are absorbed by the bracket walls and dissipated into the bracket. Key to these ground breaking results has been the design vision of the Innobrace team. In collaboration with SIMTECH, the team has identified a special titanium alloy to produce Flexibrace.
This is an illustration of a successful implementation of a medical device with the apex of material science & process engineering, something that is sure to bring a smile to both patients and orthodontic professionals and at an affordable cost too.
Something that is in line with our goals when taking that first step of this thrilling journey.
Benefits of Flexibrace:
* U.S patented with a unique & novel design created with special titanium alloy.
* No elastomeric needed - reduced bacterial plague and no spontaneous dislodgement.
* Bi-monthly instead of monthly maintenance visits
* Shorter treatment time
* More even torque & correctional force
* Up to 50% reduction in Chair time
* Lesser pain for patients due to gentler and consistent forces.
A new way to cut Orthodontic treatment time by Dr. Tan Kok Liang
Date: 18th Sept 2023 (Mon)
Time: 6.30pm - 9.30pm
Venue: 28 Senang Crescent, #02-01, Bizhub 28, S (416601)
Teeth move at the same speed regardless of what type of ligating or self-ligating bracket system is used.
Speed of tooth movement is dependent on the archwires used and not the bracket system.
A new non-ligating bracket system can shorten treatment time by allowing clinicians to advance archwires earlier in treatment.
Clinical cases will be presented to demonstrate the benefits of using a flexible non-ligating bracket system compared to a traditional rigid bracket system that will aid to advance archwire sequence.
Flexibrace Non-ligating Bracket Vs Self-ligating Bracket
Please reach out to us if you cannot find an answer to your question.
All traditional & Self-ligating Bracket (SLB) systems utilize a rigid bracket archwire slot. When an archwire is inserted, the force from the archwire is directly and completely transferred to the tooth through the bracket. If the force is excessive, the tooth will be subjected to unwanted pain and movement will be negatively affected.
With Flexibrace, the archwire walls will flex to moderate the force that is transmitted to the tooth. The force level is reduced and spread out over a long period of time to ensure that the force on the tooth is always gentle and continuous. In a clinical situation, this means that the clinician can progress to rectangular archwires earlier in the treatment. The movement of the teeth on the archwire can still be done with a 3-dimensional control even if not all the teeth are aligned.
Undoubtedly the insertion and removal of archwires can be performed more expeditiously with Flexibrace. When inserting and removing the archwires, a rocking movement will ease the archwire into and out of the brackets in an instant.
There is no need to use special pliers for removal. Chair side time is significantly reduced when using Flexibrace system.
No. it is not necessary because the wings of the bracket can be used to attach power chains and elastics. Elastomeric modules can also be used if required and in instances where rotational control is important.
Flexibrace is designed to help orthodontists to speed up the progression of archwire thickness and stiffness without compromising on patient comfort. Orthodontists are able to continue to use the same archwires that they are used to.
However, the first alignement archwire is recommended to be no smaller than 0.016" NiTi because the opening of the slot in the 0.022" system is 0.015".
When the doctor applies the archwire into the archwire slot, the slot opens up momentarily to accept and retain the archwire. There is no other clips or tiny devices that need to be activated to close the archwire slot. One benefit of Flexibrace is the flexible archwire slot which enhances clinical efficiency
The archwire slot (which is 0.022”X0.028” in the .022” system) is a rectangular space into which a doctor applies a round or rectangular archwire to effect tooth movement. In a self-ligating system, the 3 sides of this rectangle nearest to the crown surface are rigid and directly convey any forces (big or small, appropriate or inappropriate) to the crown and hence the tooth.
With the passive self-ligating system, the size of this rectangle remains the same throughout treatment. With the so-called interactive system, the fourth side of the rectangle represented by a clip can be used to reduce the size of the rectangle, compressing a suitably sized rectangular archwire with the aim of improving torque control.
Flexibrace system has flexible archwire slots, so that the rectangle slot can flex and dampen excessive forces from archwires to achieve constant light orthodontic forces. So the slot shape does not remain a rectangle during treatment. Archwire progression is quicker so that working archwires can be placed sooner and major orthodontic movements such as space closure and inter-arch mechanics can start sooner. Hence treatment time can be saved.
In addition, the flexibility of the archwire slot allow for full bracket engagement of the archwire during finishing. This feature is not possible with traditional and self ligating brackets
As the Flexibrace brackets have no hooks, crimpable hooks on archwire may be required for intermaxillary traction.
Buttons on the lingual surface are recommended to aid rotational correction.
